NM400 NM450 Most Wear Resistant Steel Plate In China

Grade: NM360, NM400, NM450, NM500, NM550, NM600
Thickness: 3-80mm
Width: 1250mm, 1500mm, 1800mm, 2000mm, 2200mm
Length: 6000mm, 8000mm, 10000mm, or cut to required.

Wear resistant steel are produced from processes of hot rolling, cutting into length and heat treating. The products are characterized with small thickness, good flatness, outstanding wear resistance, excellent toughness, good weldability, good machinablility, consistent property and quality.
Wear resistant steels are developed for applications where high wear resistant performance is required, such as dumper, garbage vehicle, concrete mixer truck, industrial air fan, hopper, crusher, machinery for coal, grain, cement, grab bucket, etc.

NM400 NM450 Wear Resistant Steel is one kind of Chinese wear/abrasion resistant steel plates, which is well received in middle east and Africa. An NM400 wear-resistant steel was hot rolled and then the plates were heat-treated by direct quenching and tempering and reheat quenching and tempering techniques, respectively. The impact test was carried out with an instrumented impact tester. The micro-structure and fracture surface were investigated by a combination of optical microscopy, transmission electron microscopy and scanning electron microscopy methods.

Chemical Composition,/%

Grade

C

Si

Mn

P

S

Cr

Ni

Mo

Ti

B

AlS

Range

NM360

0.25

0.70

1.60

0.025

0.015

0.80

0.50

0.50

0.05

0.0005-0.006

0.01

NM400

0.30

0.70

1.60

0.025

0.010

1.00

0.70

0.50

0.05

0.0005-0.006

0.01

NM450

0.35

0.70

1.70

0.025

0.010

1.10

0.80

0.55

0.05

0.0005-0.006

0.01

NM500

0.38

0.70

1.70

0.02

0.010

1.20

1.00

0.65

0.05

0.0005-0.006

0.01

Mechanical Properties

Grade

Thickness/mm

Rm/Mpa

A50/%

-20℃KV2/Jitudinal)

HBW

NM360

≤80

≥1100

≥12

≥24

330-390

NM400

≤80

≥1200

≥10

≥24

370-430

NM450

≤80

≥1250

≥7

≥24

420-480

NM500

≤70

≥1300

 ≥7

 ≥24

480-520

Packaging

bundle package; wooden case,wooden pallet package; container or bulk; special according to customer request
