China factory nm360 nm400 nm550 wear resistant steel plate
Grade: NM360, NM400, NM450, NM500, NM550, NM600
Thickness: 3-80mm
Width: 1250mm, 1500mm, 1800mm, 2000mm, 2200mm
Length: 6000mm, 8000mm, 10000mm, or cut to required.
- Description
Wear resistant steel are produced from processes of hot rolling, cutting into length and heat treating. The products are characterized with small thickness, good flatness, outstanding wear resistance, excellent toughness, good weldability, good machinablility, consistent property and quality.
Wear resistant steels are developed for applications where high wear resistant performance is required, such as dumper, garbage vehicle, concrete mixer truck, industrial air fan, hopper, crusher, machinery for coal, grain, cement, grab bucket, etc.
Applications of NM400 Plates :
The series of NM wear-resistant steel combined the properties including high strength, high hardness, high wear resistant, weldable, bendable and mainly applied in:
Edge of loaders in loader industry
Wear-resistant lining plate in crusher industry.
Slat type conveyer in colliery mechanical industry.
Lining plate of coal pulverizer in power industry.
Lining plate of hopper for heavy handling truck.
|
Chemical Composition,/% |
|||||||||||
|
Grade |
C |
Si |
Mn |
P |
S |
Cr |
Ni |
Mo |
Ti |
B |
AlS |
|
≤ |
Range |
≥ |
|||||||||
|
NM360 |
0.25 |
0.70 |
1.60 |
0.025 |
0.015 |
0.80 |
0.50 |
0.50 |
0.05 |
0.0005-0.006 |
0.01 |
|
NM400 |
0.30 |
0.70 |
1.60 |
0.025 |
0.010 |
1.00 |
0.70 |
0.50 |
0.05 |
0.0005-0.006 |
0.01 |
|
NM450 |
0.35 |
0.70 |
1.70 |
0.025 |
0.010 |
1.10 |
0.80 |
0.55 |
0.05 |
0.0005-0.006 |
0.01 |
|
NM500 |
0.38 |
0.70 |
1.70 |
0.02 |
0.010 |
1.20 |
1.00 |
0.65 |
0.05 |
0.0005-0.006 |
0.01 |
|
Mechanical Properties |
|||||
|
Grade |
Thickness/mm |
Rm/Mpa |
A50/% |
-20℃KV2/Jitudinal) |
HBW |
|
NM360 |
≤80 |
≥1100 |
≥12 |
≥24 |
330-390 |
|
NM400 |
≤80 |
≥1200 |
≥10 |
≥24 |
370-430 |
|
NM450 |
≤80 |
≥1250 |
≥7 |
≥24 |
420-480 |
|
NM500 |
≤70 |
≥1300 |
≥7 |
≥24 |
480-520 |
Packaging
bundle package; wooden case,wooden pallet package; container or bulk; special according to customer request
