Tungsten Carbide Machining
Tungsten carbide machining relies on powder metallurgy, sintering, and diamond grinding, not conventional cutting.
These advanced processes create components with unmatched hardness, extreme wear resistance, and long service life, making tungsten carbide essential for mining, oil & gas, machining, and high-wear industrial applications.
- Description
Tungsten carbide (WC) is one of the hardest engineering materials used in modern industry. It combines extreme hardness, high compressive strength, and outstanding wear resistance, which makes machining it very different from ordinary steel or stainless steel.
Because of its hardness, tungsten carbide is not machined by conventional cutting. It is processed using powder metallurgy, precision forming, and grinding technologies.
How Tungsten Carbide Is Manufactured
Tungsten carbide components are produced through a powder metallurgy process, not by melting.
Step 1 – Powder Preparation
-
Tungsten powder
-
Carbon powder
-
Cobalt or nickel binder
These materials are mixed to form tungsten carbide composite powder.
Step 2 – Ball Milling
The powder mixture is:
-
Crushed
-
Homogenized
-
Refined to micron size
This ensures uniform carbide distribution and consistent hardness.
Step 3 – Pressing
The powder is compacted into shape using:
-
Uniaxial pressing
-
Cold isostatic pressing
This forms a green compact with the final geometry.
Step 4 – Sintering
The compact is heated to about 1350–1450°C in a controlled furnace.
The binder melts and bonds the carbide grains, producing a dense, solid material.
This creates:
-
Hardness up to HRA 90+
-
Very high wear resistance
Machining After Sintering
Once sintered, tungsten carbide becomes too hard for traditional machining.
Final shaping is done using:
| Method | Purpose |
|---|---|
| Diamond grinding | Achieve final dimensions |
| EDM (electrical discharge machining) | Cut complex shapes |
| Laser cutting | Precision profiling |
| Ultrasonic machining | Micro features |
Only diamond tools can cut tungsten carbide.
Tungsten Carbide in Overlay and Cladding
In tungsten carbide overlay plates, carbide particles are:
-
Embedded in a metal matrix
-
Welded or brazed onto steel surfaces
This allows:
-
Localized wear protection
-
Strong bonding to steel substrates
These parts are not machined after welding; they are formed to shape first.
Why Tungsten Carbide Is Hard to Machine
| Property | Effect |
|---|---|
| Extreme hardness | Resists cutting |
| High brittleness | Cracks under impact |
| Low ductility | Cannot be bent or forged |
| High abrasion | Destroys normal tools |
This is why tungsten carbide is always shaped by grinding and advanced processes, not milling or turning.
Typical Tungsten Carbide Machined Products
-
Wear plates
-
Cutting tools
-
Drilling components
-
Valve parts
-
Pump seals
-
Crusher inserts
