Ar400 Wear Plate
AR400 wear plates are available in a wide range of thicknesses, widths, and lengths, making them suitable for light, medium, and heavy-duty wear applications.
Choosing the right thickness and dimensions ensures maximum wear resistance, durability, and operational efficiency in industrial equipment.
- Description
AR400 wear plate is a high-hardness, abrasion-resistant steel widely used in mining, construction, cement, and heavy machinery.
Its versatility is enhanced by the availability of various thicknesses, widths, and lengths, allowing customization for different industrial applications.
1. Standard Thickness
| Thickness (mm) | Common Uses |
|---|---|
| 6–8 | Light wear applications: chutes, small hoppers, protective panels |
| 10–12 | Medium wear applications: conveyor liners, mixer blades |
| 16–20 | Heavy wear areas: bucket liners, crusher liners, dump truck beds |
| 25–50 | Extreme wear applications: industrial hoppers, heavy-duty machinery parts |
2. Standard Width and Length
| Width (mm) | Length (mm) | Notes |
|---|---|---|
| 1500–2000 | 3000–6000 | Most common for industrial plates, easy for transportation and fabrication |
| 2000–2500 | 6000–12000 | Large plates for heavy-duty equipment or custom cutting |
Notes:
-
Standard widths are usually 1500 mm or 2000 mm, depending on manufacturer.
-
Lengths range from 3000 mm to 12000 mm, often customized for specific industrial equipment.
-
Plates can be cut, drilled, or welded to meet application requirements.
3. Applications by Plate Size
| Plate Thickness | Industrial Application |
|---|---|
| 6–8 mm | Small hoppers, guards, light conveyors |
| 10–12 mm | Mixer blades, medium-duty chutes, conveyor liners |
| 16–20 mm | Excavator buckets, crusher liners, heavy-duty conveyors |
| 25–50 mm | Industrial hoppers, dump truck bodies, high-abrasion mining equipment |
