CCO Plate: Common Thickness and Size Specifications of Chromium Carbide Overlay Plate
CCO plate (Chromium Carbide Overlay Plate) is a bimetallic wear-resistant steel plate composed of a mild steel base and a hard chromium carbide overlay layer. Its performance is defined not only by material composition but also by its base plate thickness, overlay thickness, and total plate size.
Different thickness combinations are designed to meet various wear conditions, from light abrasion to extreme heavy-duty mining applications.
1. Common CCO Plate Thickness Structures
CCO plates are usually expressed in the format: base plate thickness + overlay layer thickness.
| Specification | Total Thickness | Wear Condition |
|---|---|---|
| 4+3 mm | 7 mm | Light abrasion |
| 6+4 mm | 10 mm | General industrial wear |
| 6+6 mm | 12 mm | Medium abrasion |
| 8+4 mm | 12 mm | Impact + abrasion |
| 8+6 mm | 14 mm | Heavy-duty wear systems |
| 10+6 mm | 16 mm | Mining and cement industry |
| 12+8 mm | 20 mm | Extreme abrasion conditions |
2. Common Overlay Thickness Range
| Overlay Thickness | Wear Resistance Level |
|---|---|
| 3–4 mm | Standard wear protection |
| 5–6 mm | High wear resistance |
| 7–8 mm | Severe abrasion conditions |
| 10 mm+ | Extreme wear environments |
3. Common Plate Size (Width & Length)
In addition to thickness, CCO plates are also supplied in standard sheet sizes:
| Item | Common Range |
|---|---|
| Width | 1000 mm – 3000 mm |
| Length | 2000 mm – 6000 mm |
| Cut-to-size | Available based on customer requirements |
4. Standard Plate Formats
- Flat plates: Used for liners and structural wear protection
- Cut pieces: Custom shapes for chutes, hoppers, and ducts
- Fabricated parts: Welded wear assemblies
5. How Thickness Affects Performance
- Thicker base plate: Better structural strength and impact resistance
- Thicker overlay: Longer wear life in abrasive conditions
- Balanced design: Optimized for both wear and service life
6. Application Matching by Thickness
| Application | Recommended Specification |
|---|---|
| Light conveyor systems | 4+3 mm / 6+4 mm |
| General mining equipment | 6+6 mm / 8+4 mm |
| Cement plant chutes | 8+6 mm / 10+6 mm |
| Heavy mining & crushers | 12+8 mm |
7. Teda Ganghua CCO Plate Supply Capability
As a professional wear-resistant steel supplier, Teda Ganghua provides chromium carbide overlay plates in a full range of thickness combinations and sizes. We support customized cutting, lining fabrication, and engineering wear solutions for mining, cement, steel, and power industries.
Explore our wear-resistant steel products here:
Wear Resistant Steel Plates
Conclusion
CCO plate is available in multiple thickness combinations ranging from 4+3 mm to 12+8 mm, with flexible width and length options. Different configurations are selected based on wear intensity, impact level, and structural requirements.
