Plate Corten Steel
Plate Corten steel is available in a wide range of thicknesses, widths, and lengths to meet different structural and architectural needs.
Typical specifications include:
-
Thickness: 1.5 mm to 40 mm
-
Width: 1000 mm to 2000 mm
-
Length: 2000 mm to 6000 mm
- Description
Plate Corten steel, also known as weathering steel plate, is widely used in construction, architecture, and landscape engineering. This type of steel contains alloying elements such as copper, chromium, and nickel, which allow the surface to form a protective rust-like patina when exposed to outdoor environments.
Because of its corrosion resistance and distinctive appearance, Corten steel plates are commonly used for building facades, bridges, garden structures, and outdoor decorative panels.
Common Thickness of Corten Steel Plates
Corten steel plates are typically produced in both thin sheets and heavy structural plates. The available thickness depends on the rolling process.
| Thickness Range | Plate Type | Typical Applications |
|---|---|---|
| 1.5 – 3 mm | Thin sheet | Decorative panels, small garden products |
| 3 – 6 mm | Medium plate | Landscape edging, planters, architectural cladding |
| 6 – 12 mm | Structural plate | Outdoor structures and heavy-duty landscaping |
| 12 – 40 mm | Heavy plate | Bridges, large steel structures |
For most landscape and architectural projects, plates between 2 mm and 6 mm are commonly used because they balance strength, weight, and fabrication flexibility.
Standard Width and Length
Corten steel plates follow common steel plate production dimensions used in the industry.
| Width | Length | Notes |
|---|---|---|
| 1000 mm | 2000 mm | Common small plate size |
| 1219 mm | 2438 mm | Equivalent to 4 ft × 8 ft sheet |
| 1500 mm | 3000 mm | Standard architectural plate |
| 2000 mm | 6000 mm | Large structural plates |
The 4 × 8 ft sheet size (1219 × 2438 mm) is one of the most frequently used sizes for fabrication and architectural panels.
Coil and Plate Conversion
Weathering steel can also be produced as steel coils, which are later cut into plates or sheets according to project requirements.
Typical coil specifications include:
| Parameter | Typical Range |
|---|---|
| Coil Thickness | 1.5 – 6 mm |
| Coil Width | 1000 – 1500 mm |
| Processing | Cutting, slitting, bending |
This allows manufacturers to produce custom plate sizes and shapes for different applications.
Typical Applications of Plate Corten Steel
Corten steel plates are widely used in outdoor projects because of their durability and natural rust appearance.
Common applications include:
-
Architectural cladding panels
-
Bridge structural plates
-
Landscape garden structures
-
Outdoor sculptures and decorative walls
-
Tree grates and planter boxes
These applications benefit from the steel’s weather resistance and minimal maintenance requirements.
